  • Round Pin Chain Shackles
  • Line Drawing for US Round Pin Chain Shackles
The stainless steel chain shackles feature an oversize round pin and are made from grade 316 stainless steel for maximum corrosion resistance. These chain shackles are ideal for industrial and marine applications and are available in multiple sizes. I/A/W Fed Spec RR-C-271, Type IVB, Class 1, (except 316 stainless steel).
1 - 6 of 6 | Results Per Page | View | Unit of Measure
1
Request Information Compare Items

Item #

Item Name

Dimension A

Dimension B

Dimension C

Material

N/A US Round Pin Chain Shackle N/A 1/4 in N/A 0.32 in N/A 0.46 in N/A 316-NM Stainless Steel
N/A US Round Pin Chain Shackle N/A 5/16 in N/A 0.38 in N/A 0.52 in N/A 316-NM Stainless Steel
N/A US Round Pin Chain Shackle N/A 3/8 in N/A 0.44 in N/A 0.65 in N/A 316-NM Stainless Steel
N/A US Round Pin Chain Shackle N/A 7/16 in N/A 0.50 in N/A 0.75 in N/A 316-NM Stainless Steel
N/A US Round Pin Chain Shackle N/A 1/2 in N/A 0.63 in N/A 0.79 in N/A 316-NM Stainless Steel
N/A US Round Pin Chain Shackle N/A 1 in N/A 1.13 in N/A 1.67 in N/A 316-NM Stainless Steel
