  • Bow/Stern Eye
  • Line Drawing for Bow/Stern Eye
The Bow/Stern Eye is UNC thread and available in sizes ranging from 3/8" to 1/2". Each u-bolt includes four nuts (two standard and two bevelled), one bow plate and one stern plate. It is made from grade 304 stainless steel for corrosion resistance and durability, making it perfect for marine applications.
1 - 9 of 9 | Results Per Page | View | Unit of Measure
1
Request Information Compare Items

Item #

Item Name

Dimension A

Dimension B

Dimension C

Material

N/A Bow/Stern Eye N/A 3/8 in N/A 1.03 in N/A 1.13 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 3/8 in N/A 1.03 in N/A 3.00 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 3/8 in N/A 1.03 in N/A 4.00 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 7/16 in N/A 1.50 in N/A 3.44 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 7/16 in N/A 1.50 in N/A 4.50 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 1/2 in N/A 1.31 in N/A 2.50 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 1/2 in N/A 1.31 in N/A 3.44 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 1/2 in N/A 1.31 in N/A 4.75 in N/A 304 Stainless Steel
N/A Bow/Stern Eye N/A 1/2 in N/A 1.31 in N/A 6.00 in N/A 304 Stainless Steel
